| Product Model |
22A‑D8P7N104 |
| Manufacturer |
Allen‑Bradley / Rockwell Automation |
| Product Type |
Variable Frequency Drive (AC Drive) |
| Series |
PowerFlex 4 |
| Power Rating |
3.7 kW (5.0 HP) |
| Input Voltage |
380‑480V AC, 3‑Phase (±10%) |
| Output Current |
8.7 A |
| Input Current |
9.0 A |
| Output Voltage |
0‑460V AC, 3‑Phase |
| Output Frequency |
0‑240 Hz |
| Input Power |
8.6 kVA |
| Enclosure Rating |
IP20 / NEMA UL Type Open |
| Frame Size |
Frame B |
| Mounting Type |
Panel Mount / DIN Rail |
| Keypad Type |
LED Display with Fixed Digital Keypad |
| Communication |
RS485 (Modbus RTU) |
| Brake Drive |
Integral IGBT Brake |
| Overload Capacity |
150% for 60 seconds, 200% for 3 seconds |
| Dimensions (L × W × D) |
180 × 100 × 136 mm |
| Weight |
1.81 kg (4.0 lbs) |
| Operating Temperature |
0°C to +50°C |
| Overvoltage Trip |
810V DC bus (≈575V AC incoming) |
| Undervoltage Trip |
390V DC bus (≈275V AC incoming) |
| Country of Origin |
China |
| Lifecycle Status |
Discontinued (Replacement: 25A‑D010N104) |
