Technical Specifications
| Parameter Name | Value |
|---|---|
| Product Model | 6AV7674-0KA00-0AA0 |
| Manufacturer | Siemens AG |
| Product Type | HMI Basic Adapter / Installation Adapter Plate |
| Product Series | SIMATIC HMI Accessories |
| Compatible Display Ratio | 4:3 PRO devices |
| Color | RAL 9023 (Light gray) |
| Scope of Delivery | 1 pipe adapter, mounting hardware (including 4 screws) |
| Supported Cutout (New HMI) | 176 mm x 134 mm (for TP177A/TP177B/KTP600 Basic) |
| Compatible Legacy Cutout | 138 mm x 76 mm (for OP7/OP17) |
| Country of Origin | Germany (DE) |
| Customs Tariff Number | 84733080 |
| RoHS Compliance | Conforms |
| Product Lifecycle | Active |
Main Features and Advantages
Seamless retrofitting capability: The Siemens 6AV7674-0KA00-0AA0 eliminates the need for cabinet rework when upgrading from legacy HMI devices to newer SIMATIC panels. This adapter plate bridges the dimensional gap between old and new panel cutouts, reducing installation time and cost by up to 80% compared to manual cabinet modifications. The Siemens 6AV7674-0KA00-0AA0 is specifically designed to fit TP177A, TP177B, and KTP600 Basic panels into OP7 and OP17 cutouts .
Complete installation kit: Each Siemens 6AV7674-0KA00-0AA0 ships with all necessary mounting hardware, including the pipe adapter and screws, ensuring a complete and hassle-free installation . This comprehensive scope of supply minimizes the need for additional parts procurement and simplifies the upgrade process for maintenance teams.
PRO device compatibility: The Siemens 6AV7674-0KA00-0AA0 is designed for use with all fully enclosed 4:3 PRO HMI devices, making it a versatile solution for standard SIMATIC HMI installations . It is particularly suitable for arm-mounted configurations where the adapter facilitates proper cable routing through the support arm, maintaining the integrity of the industrial design and cable management.
Robust and reliable construction: Manufactured in Germany to Siemens’ stringent quality standards, the Siemens 6AV7674-0KA00-0AA0 offers the durability expected of industrial accessories. Its RoHS-compliant construction ensures environmental responsibility while maintaining the mechanical integrity required for long-term service in demanding industrial environments .
Application Fields
The Siemens 6AV7674-0KA00-0AA0 is primarily deployed in industrial modernization and retrofit projects, where existing manufacturing lines require HMI upgrades without extensive cabinet modifications. In the automotive industry, the Siemens 6AV7674-0KA00-0AA0 enables cost-effective replacement of legacy operator panels on production line control stations and assembly machines, allowing manufacturers to adopt newer HMI technology while preserving existing cabinet infrastructure.
In food and beverage, pharmaceutical, and packaging industries, the Siemens 6AV7674-0KA00-0AA0 facilitates the migration from older OP7/OP17 panels to newer TP177A, TP177B, or KTP600 Basic panels, supporting enhanced operator interfaces and improved diagnostics . This upgrade path, enabled by the Siemens 6AV7674-0KA00-0AA0, allows facilities to maintain equipment reliability while gaining access to modern HMI features such as enhanced alarm management, improved graphics, and advanced recipe handling capabilities.
For machine builders and system integrators, the Siemens 6AV7674-0KA00-0AA0 provides flexibility in standardizing on modern HMI platforms while accommodating legacy cabinet designs. This reduces engineering time for upgrade projects and simplifies spare parts management. The Siemens 6AV7674-0KA00-0AA0 ensures that the transition to newer HMI devices is straightforward and minimally disruptive to production operations.
