PROSOFT MVI56-PDPMV1 processor

PROSOFT MVI56-PDPMV1 processor

PROSOFT MVI56-PDPMV1

Product Details:
Country of Origin: USA
Brand:PROSOFT
Model:MVI56-PDPMV1
Minimum order quantity :1 item
Packaging parts: raw materials for new plant and separate packaging
Delivery time :2-3 working days
Payment: Bank transfer, Western Union

Description

PROSOFT MVI56-PDPMV1

The PROSOFT MVI56-PDPMV1 module is a PROFIBUS DP-V1 master station communication module for ControlLogix® processors and is used to connect ControlLogix® processors to the PROFIBUS DP-V1 network. The module has the following features:

Supports the full PROFIBUS-DP master station specification according to IEC 61158
Acyclic parameter data can be transferred through the DPV1 service of Class 1 or Class 2
Supports communication rates up to 12Mbit/s

Have diagnostic function
Easy to use
Product parameter
Model: PROSOFT MVI56-PDPMV1
Network connection: 1 RS-485 interface
Communication rate: 9.6Kbps, 19.2Kbps, 57.6Kbps, 115.2Kbps, 1.5Mbit/s, 3Mbit/s, 6Mbit/s, 12Mbit/s
Protocol: PROFIBUS DP-V1
Rated voltage: 24V DC
Power consumption: <10W
Size: 80mm x 45mm x 25mm
Weight: 0.2kg
