PR0S0FT PTQ-PDPMV1

ProSoft Technology PTQ-PDPMV1 module is a PROFIBUS DP V1 master station module, mainly used to connect the field equipment that supports the PROFIBUS DP protocol to the PLC and other controllers. It acts as a bridge, transmitting the data on the PROFIBUS network to the controller to realize the control and monitoring of the field equipment.

Product name
Chinese name: ProSoft Technology PTQ-PDPMV1 PROFIBUS DP V1 master station module

English name: ProSoft Technology PTQ-PDPMV1 PROFIBUS DP V1 Master Module
Product description
The PTQ-PDPMV1 module was developed by ProSoft Technology for the interconnection between different automation devices. It supports the full PROFIBUS DP V1 master specification and can communicate with various PROFIBUS DP slave devices. The module is typically mounted on the PLC rack and is set up via configuration software for seamless integration with the PLC.

Main feature
PROFIBUS DP V1 master: Supports the full PROFIBUS DP V1 master specification.
Flexible configuration: Multiple PROFIBUS slave stations can be configured to support multiple data types.
Easy to use: Provides configuration software for users to configure.
High reliability: industrial grade design, with good reliability.
Strong compatibility: can be compatible with a variety of PLCS.
Product parameters (part)
Communication interface: PROFIBUS DP V1
Data transmission rate: 9.6kbps~12Mbps
Number of nodes: A maximum of 31 slave nodes are supported
Operating temperature: 0℃~55℃
Product specification
Mounting method: DIN rail mounting
Power supply: from PLC
Product application
Process control: Used to connect PROFIBUS DP device to achieve process control.
Data acquisition: Used to collect field data for data analysis.
Device monitoring: Used to monitor the running status of the device.
