PIONEER MAGNETICS PM36218B-10P-1-8PH-J Analog output module

PIONEER MAGNETICS PM36218B-10P-1-8PH-J

Product Details:
Country of Origin: USA
Brand:PIONEER
Model:MAGNETICS PM36218B-10P-1-8PH-J
Minimum order quantity :1 item
Packaging parts: raw materials for new plant and separate packaging
Delivery time :2-3 working days
Payment: Bank transfer, Western Union

PIONEER MAGNETICS PM36218B-10P-1-8PH-J

Pioneer magnetoelectric PM36218B-10P-1-8PH-J module is a 10-channel analog output module, belongs to Pioneer magnetoelectric PM3600 series module. The module provides 10 analog output channels, which can be used to output voltage or current signals, control inverter, servo motor and other equipment.

Product parameter
Main parameter

Module type: analog output module

Number of channels: 10
Output type: voltage, current
Output range:

Voltage: 0-10V, 0-20V, ±10V, ±20V
Current: 0-20mA, 4-20mA
Resolution: 12 bits
Accuracy: 0.1%
Update rate: 1000Hz
Isolation: channel to channel, channel to ground
Mounting method: DIN rail mounting
Other parameters

Module size: 115mm x 87mm x 25mm
Weight: 0.3kg
Power consumption: 1.2W
Ambient temperature: -20℃ ~ +60℃
Storage temperature: -40℃ ~ +85℃
Relative humidity: 5% ~ 95% (no condensation)
