MITSUBISHI MR-J2S-22KB

Mitsubishi Electric MR-J2S-22KB module is a servo driver module for Mitsubishi Electric MELSERVO-J2S series servo systems. The module can control the three-phase AC servo motor, which has the characteristics of high precision, high response speed and high reliability.

Product parameter
Rated output current: 22A
Rated output voltage: 230VAC
Power: 5.5kW
Control mode: Pulse width modulation (PWM)

Velocity resolution: 0.001r/min
Speed control range: 0.01r/min to 3000r/min
Torque control range: 0% to 150%
Overload capacity: 150% (1 minute)
Inertia matching: automatic
Position control accuracy: ±0.001mm

Speed control accuracy: ±0.01%
Response speed: 1ms
Communication interface: RS-485
specification
Dimensions: 280mm x 185mm x 90mm
Weight: 2.5kg
