IFM F01H.M05.235 IE5287

Product name: IFM F01H.M05.235 IE5287 module

Product Description:

The IFM F01H.M05.235 IE5287 module is a 16-channel digital input/output module for the IFM IE5287 series PLC. It is used to collect switching signals from external devices, such as buttons, sensors and switches, and to control external devices, such as motors, lights and valves. The module has the following functions:

16 digits input
16 digital output
The maximum current for each input is 20 mA
The maximum current of each output is 100 mA
Input voltage range: 0 to 24 V DC
Output voltage range: 0 to 24 V DC
Product parameters:

Connector type: 2-pin DIN connector
Communication protocol: Modbus RTU
Communication rate: 9600 bps
Power supply voltage: 24 V DC
Power supply current: 100 mA
Specifications:

Input type: numeric quantity
Input status: Normally open (NO) or normally closed (NC)
Maximum current: 20 mA
Maximum voltage: 24 V DC
Input voltage range: 0 to 24 V DC
Output type: numeric quantity
Output status: Normally open (NO) or normally closed (NC)
