GE IC698CMX016

The GE IC698CMX016 module is the I/O module of GE’s PACSystems RX7i series security systems. The module can be used to collect various analog and digital signals and convert them into signals available to the control system.

Product parameter

Type: Analog input, analog output, digital input, digital output

Number of channels: 8, 16, 32
Resolution: 12 bits, 16 bits
Update rate: 100 Hz, 1 kHz, 10 kHz
Input range:
Voltage: ±10 V, ±5 V, ±1 V
Current: ±20 mA, ±10 mA, ±4 mA
Output range:
Voltage: ±10 V, ±5 V, ±1 V
Current: ±20 mA, ±10 mA, ±4 mA
specification

Size: 4HP, 8HP
Power Supply: 24 Vdc
Power consumption: 2 W, 4 W
Ambient temperature: 0 to 60 °C
Humidity: 5% to 95% (non-condensing)
Apply

Industrial control
Process control
