GE IC695CPE310

The GE IC695CPE310 module is a CPU module for PACSystems RX3i series programmable logic controllers. This module is the core component of the RX3i series and is responsible for executing user programs and controlling the operation of the system.

Product parameter
CPU type: Intel 386EX
Instruction set: IEC 61131-3
Storage capacity: 512K
Speed: 0.25μs/ instruction

Communication port: RS-232, RS-485

Dimensions: 120 x 70 x 80 mm
Weight: 0.3kg
specification
CPU

Type: Intel 386EX
Instruction set: IEC 61131-3
Storage capacity: 512K
Speed: 0.25μs/ instruction
Internal memory

Type: SRAM
Capacity: 512K
communication

Port: RS-232, RS-485
Power source

Voltage: 24V DC
Power consumption: 10W
environment

Operating temperature: -20°C to 70°C
Storage temperature: -40°C to 85°C
Humidity: 5% to 95% (non-condensing)
