B&R 8MSA4X.R0-67

The B&R 8MSA4X.R0-67 module is a 4-channel analog output module for the B&R Automation X20 series controllers. It can convert digital signals into voltage or current signals and output them to external devices. The module has the characteristics of high precision, high reliability and easy installation.

Product parameter
Output type: voltage or current
Output range:

Voltage: 0V ~ 10V, 0V ~ 5V
Current: 0mA ~ 20mA, 0mA ~ 10mA
Resolution: 16 bits

Accuracy: ±0.1%
Sampling rate: 1000 times/second
Interface:
One RJ-45 Ethernet port
One optical fiber port
Operating temperature: -40℃ ~ 70℃
Storage temperature: -55℃ ~ 85℃
Relative humidity: 5% ~ 95%
Overall dimensions: 110mm x 70mm x 40mm
Weight: 0.2kg
Product characteristics
High accuracy: 16-bit resolution, ±0.1% accuracy
High reliability: redundancy design, low failure rate
Easy to install: plug and play
Suitable for various industrial applications
Application field
Electric power system
Petrochemical industry
metallurgy
Water treatment
transportation
