Agilent HP 5517B
Product description
The Agilent HP 5517B is a high-performance laser displacement sensor module for precision measurement applications. It has the following characteristics:
High precision
High resolution
Non-contact measurement
Fast response
Easy to use
Product parameter
Parameter value
Measuring range ±25 mm
Accuracy ± 0.1μm
Resolution 0.01 μm
Measuring speed 1 kHz
Interface RS-232, GPIB
Power supply voltage 24 VDC
Power consumption < 10 W
Operating temperature 0°C to +40°C
Storage temperature -20°C to +60°C
specification
Specification value
Dimensions 100 x 50 x 20 mm
Weight 0.5kg
Apply
The Agilent HP 5517B laser displacement sensor module can be used in a wide range of precision measurement applications, including:
Semiconductor manufacturing
Optical device manufacturing
machining
Scientific research experiment
