ABB TB850

Description: The ABB TB850 module is a 16-channel analog input/output module for the ABB 800xA control system. It provides 8 analog input channels and 8 analog output channels, which can be used to monitor and control various process variables.

** Product Parameters:

Analog input type: voltage input, current input
Analog input voltage range: 0~10V, -10~10V
Analog input current range: 0~20mA, -20~20mA
Resolution: 16 bits
Analog output type: voltage output, current output

Analog output voltage range: 0~10V, -10~10V
Analog output current range: 0~20mA, -20~20mA
Resolution: 16 bits
Response time: <10μs
Dimensions: 90mm x 90mm x 15mm
** Specifications:

Operating temperature: -25°C~+60°C
Storage temperature: -40°C to +70°C
Relative humidity: 5%~95% (non-condensing)
Seismic rating: IP67
