ABB 3HAC025338-006

The ABB 3HAC025338-006 is an analog input/output module for converting analog signals to digital signals or digital signals to analog signals. It has the following characteristics:

16 analog input channels

16 analog output channels
Supports a variety of analog signal types, including voltage, current, frequency, pulse, etc
Provides extensive diagnostic functions to help you quickly locate faults
The module can be used for a variety of applications, including:

Collect analog signals such as temperature, pressure and flow rate

Control motor, valve and other equipment
Implement data communication between the controller and external devices
Expand the functions of the controller
Product parameter
Parameter value
Model 3HAC025338-006
Analog input channel 16
Analog output channel 16
Analog signal type Voltage, current, frequency, pulse
Input range ±10V, ±20mA, 4-20mA, 0-10V
Output range ±10V, ±20mA, 4-20mA, 0-10V
Resolution 16 bit
Accuracy 0.1%
Sampling rate 1kHz
Communication interface RS-232, RS-485, Ethernet
Power supply 24VDC
