ABB RED670

Product name: ABB RED670 module

Product Description:

ABB RED670 module is an intelligent microcomputer protection dev

ice of ABB. It is designed for the protection, monitoring and control of overhead lines and cables, enabling the protection of up to 5 terminated lines.

The RED670 module has the following functions:

Split-phase line differential protection: detects and isolates single-phase, two-phase, and three-phase faults in three-phase lines.
Single-phase/two-phase/three-phase tripping and automatic reclosing: Quick tripping in the event of a fault and automatic reclosing after the fault is eliminated.
Synchronous, simultaneous detection, no voltage detection and automatic reclosing: This ensures that reclosing is performed synchronously and that automatic tripping occurs in the event of no voltage failure.

Powerful interlock function: Potentially dangerous or hazardous switchgear operations can be avoided.
Product parameters:

Power Supply: 24 V DC
Communication: Modbus RTU, PROFINET, EtherNet/IP
Dimensions: 100 x 76 x 25 mm
Weight: 0.3 kg
Specifications:

Split-phase line differential protection: Supported
Single-phase/two-phase/three-phase trip and automatic reclosing: Supported
Synchronous, simultaneous detection, no voltage detection and automatic reclosing: Supported
Powerful interlocking function: Supported
Application field:

ABB RED670 modules can be used in a variety of industrial applications, such as:

Power station
substation
