ABB CI869

ABB CI869 is a communication interface module designed by ABB for the AC 800M control system. It is connected to the AF 100 fieldbus via twisted pair (TWP), enabling communication between the AC 800M controller and other AC 800M, AC 160, or connection servers. The CI869 module integrates a twisted pair modem to provide reliable communication in harsh industrial environments.

Product characteristics

Twisted pair communication: It is connected to the AF 100 fieldbus through twisted pair to achieve point-to-point or multipoint communication.
Redundant design: Supports redundant cables and communication interfaces to improve system reliability.
Hot swap: Supports hot swap for easy maintenance and replacement.
Flexible configuration: Can be configured as a slave station to receive data from other AF 100 stations/devices.
Strong compatibility: Seamless integration with ABB AC 800M control system.

Product parameters (partial, detailed parameters please refer to the product data manual)
Communication protocol: ABB Advant Fieldbus 100
Transmission rate: 1.5 Mbit/s
Operating temperature: -20℃~+60℃
