Product Name: ABB 5SHX2645L0004 IGBT Power Module (High-Voltage Drive Dedicated)
Product Description:
A high-power insulated-gate bipolar transistor (IGBT) module designed for ABB’s medium-voltage drives (e.g., ACS800 series). It serves as the core power switching component, converting DC voltage to adjustable AC output for controlling large motors in industrial applications (e.g., pumps, fans, compressors). The module integrates advanced IGBT chips with low conduction losses, enabling efficient power conversion in high-voltage systems (up to 3.3kV).
Technical Parameters:
- Voltage Rating: 3.3kV
- Current Rating: 450A (continuous)
- Switching Frequency: Up to 10kHz
- Mounting: Press-fit baseplate for thermal management
- Isolation Voltage: 6kV RMS
Specifications:
- Dimensions: 190mm × 140mm × 45mm
- Weight: ~1.8kg
- Operating Temperature: -40°C~+125°C (junction)
- Certifications: IEC 60747, RoHS
2. 3BHL000389P0104
Product Name: ABB 3BHL000389P0104 Control Board (ACS880 Drive Dedicated)
Product Description:
A key control board for ABB ACS880 industrial drives, responsible for managing drive logic, sensor inputs, and communication with external systems. It processes feedback signals (e.g., motor speed, current) to regulate drive output, ensuring precise motor control. The board supports multiple industrial protocols, enabling integration with PLCs and SCADA systems.
Technical Parameters:
- Processor: 32-bit ARM Cortex-M4
- Inputs: 8 digital inputs (24V DC), 2 analog inputs (4-20mA)
- Communication: RS485 (Modbus RTU), Ethernet (PROFINET optional)
- Power Supply: 5V DC ±10%
Specifications:
- Dimensions: 120mm × 80mm × 20mm
- Weight: ~120g
- Operating Temperature: -25°C~+70°C
- Certifications: CE, UL 508
3. 3BHB003154R0101
Product Name: ABB 3BHB003154R0101 Power Supply Module (Industrial Control System Dedicated)
Product Description:
A redundant power supply module for ABB’s distributed control systems (DCS) and PLCs, providing stable 24V DC power to control components. It features 1+1 redundancy to ensure uninterrupted operation—if one channel fails, the other automatically takes over. The module includes overload and short-circuit protection, making it suitable for critical applications (e.g., power plants, chemical processing).
Technical Parameters:
- Input Voltage: 110-240V AC (50/60Hz)
- Output Voltage: 24V DC ±2%
- Output Current: 10A (total, 5A per channel)
- Efficiency: >85% at full load
