2098-DSD-020X
The 2098-DSD-020X module is a high-performance digital servo drive module designed to control servo motors in precision motion control applications. It integrates advanced control algorithms, power electronics, and communication interfaces to deliver accurate speed, position, and torque control, making it ideal for industrial machinery such as robotic arms, CNC machines, and packaging equipment.
In a CNC machining center, this module controls a 20kW servo motor, achieving a positioning accuracy of ±0.001mm and a speed regulation range of 1:10000. It processes encoder feedback signals (up to 1MHz) in real time, adjusting motor output within 50µs to compensate for load variations, reducing machining errors by 18%. During high-speed contouring operations, the module’s feedforward control minimizes following error, ensuring smooth surface finishes on complex workpieces. In a robotic assembly line, the 2098-DSD-020X module coordinates the motion of 6 axes, with its synchronized control capability (±1µs between axes) enabling precise pick-and-place operations at speeds of up to 50 cycles per minute, increasing production throughput by 25%.
Built with rugged components and featuring robust thermal management, the module operates reliably in high-vibration and temperature-fluctuating environments. It supports multiple feedback types and industrial communication protocols, facilitating seamless integration with PLCs and motion controllers. Widely us
