Product Overview
The 1606-XLS240E is an Allen-Bradley Bulletin 1606-XLS switched-mode power supply, manufactured by Rockwell Automation, designed for mounting on a standard DIN rail in industrial control panels. Its purpose is to convert a single-phase alternating-current mains supply into a regulated 24 VDC control voltage for PLCs, I/O modules, operator interfaces, sensors, contactor coils, relays and other automation devices. The 1606-XLS240E is therefore a primary power source for the control circuit, not a DC/DC converter, not a redundant module and not a battery charger.
The 1606-XLS240E has a continuous power rating of 240 W at 24 VDC, which corresponds to a 10 A output. The output voltage is adjustable from 24 to 28 VDC, allowing the supply to compensate for voltage drop in long 24 VDC wiring runs or to suit equipment with a higher nominal operating voltage. The wide-range AC input accepts 100–120 VAC and 200–240 VAC at 50/60 Hz with automatic range selection, so the same unit can be installed across a broad range of international supply voltages without manual voltage-range switching.
The 1606-XLS240E is positioned in the 1606-XLS family as a compact, high-efficiency switched-mode supply with built-in output-side performance features. Its NEC Class 2 output compliance makes it suitable for control circuits where power-source limitations are part of the installation design. The combination of efficiency, adjustable output, output current boost and remote-control capability makes the 1606-XLS240E a practical choice for control panels that must support demanding inrush and pulsed loads without moving to a much larger supply.
Technical Specifications
| Parameter Name | Parameter Value |
|---|---|
| Product Model | 1606-XLS240E |
| Manufacturer | Allen-Bradley / Rockwell Automation |
| Product Family | Bulletin 1606-XLS Switched-Mode Power Supplies |
| Product Type | DIN-Rail Mounted Switched-Mode Power Supply |
| Input Voltage | 100–120 VAC and 200–240 VAC, single-phase |
| Input Frequency | 50/60 Hz |
| Input Current | 2.6 A at 120 VAC; 1.5 A at 240 VAC |
| Input Inrush Current | 10 A at 120 VAC; 16 A at 240 VAC |
| Fuse Requirement | 10 A maximum slow-blow |
| Output Voltage | 24 VDC nominal, adjustable 24–28 VDC |
| Continuous Output Power | 240 W |
| Continuous Output Current | 10 A |
| Efficiency | 92% typical |
| Power Factor | 0.98 at 230 VAC typical |
| Inrush Limiting | Active inrush-current limiting |
| Permanent Power Boost | 120% rated output current |
| Short-Time Power Boost | 150% rated output current for 5 seconds, repeatable every 5 seconds |
| Parallel Operation | Two units can be paralleled for redundancy or increased capacity |
| Output Ride-Through | 20 ms at 120 VAC input; 100 ms at 240 VAC input |
| Hold-Up Time | 11–17 ms |
| Output Ripple | Less than 100 mV peak-to-peak typical |
| Output Adjustment | +10%/-0% |
| Output Protection | Short-circuit, overload, overvoltage and overtemperature protected |
| Status Indication | Three LEDs for input, output and overload/fault indication |
| Remote Functions | Remote reset and remote on/off through a digital input |
| Connection Method | Screw-type terminals for AC input and DC output |
| Output Classification | NEC Class 2 compliant |
| Mounting | 35 mm DIN rail |
| Dimensions | 123 mm H × 80 mm W × 123 mm D (approx. 4.84 × 3.15 × 4.84 in) |
| Weight | 0.75 kg (approx. 1.65 lb) |
| Operating Temperature | -25–70 °C; derate linearly from 60 °C to 50% at 70 °C |
| Storage Temperature | -40–85 °C |
| Humidity | 5–95%, non-condensing |
| Vibration | 1.4 G operational |
| Shock | 30 G operational |
| Approvals | cULus, UL 508, CE, CB Scheme |
| Life Expectancy | 70,000 hours at 40 °C typical |
| Lifecycle Status | Active product line; verify availability of the specific -E variant |
