ABB 5SHY4045L0006 3BHB030310R0001
ABB 5SHY4045L0006 3BHB030310R0001 Medium-Voltage IGBT Power Module (serves as a “high-efficiency energy conversion core” in industrial medium-voltage systems, specializing in reliable AC-DC and DC-AC power conversion. With enhanced IGBT technology and rugged design, it delivers stable performance for medium-voltage drives, renewable energy converters, and industrial power supplies)
Product Description
The ABB 5SHY4045L0006 3BHB030310R0001 is an advanced medium-voltage IGBT power module engineered for demanding industrial applications, including medium-voltage motor drives in mining operations, grid-tie inverters in solar farms, and traction converters for heavy-duty locomotives. In a large mining conveyor system, this module acts as the key power conversion unit in the 6kV drive system, converting grid AC power into variable-frequency power to control conveyor speed (0-1000rpm) with precision (±0.2rpm). Its low switching losses (≤70mJ per cycle) and high efficiency (≥98.7% at rated load) reduce energy consumption by 10-15% compared to conventional modules, while its robust thermal design ensures continuous operation even in dusty, high-temperature environments (up to 70°C ambient).
In utility-scale solar farms, the module integrates into central inverters to convert DC power from solar arrays into grid-compliant AC power. It supports wide voltage input ranges (1000-1500V DC) and features advanced MPPT (Maximum Power Point Tracking) algorithms, increasing energy harvest by 2-3% annually. The module’s redundant design allows parallel operation of up to 10 units, enabling system scalability up to 5MW. Equipped with comprehensive protection mechanisms—including overcurrent (1.8x rated current), overvoltage (120% DC bus), and overtemperature (150°C junction)—it responds to faults within 6μs, minimizing downtime and protecting downstream equipment. Its compact form factor and standardized mounting interface simplify integration into existing inverter designs, accelerating time-to-market for renewable energy systems.
