XVC724BE102 3BHE009017R0102
| Item | Details |
|---|---|
| Product Name | ABB XVC724BE102 3BHE009017R0102 Excitation Control Module |
| Product Description | The XVC724BE102 3BHE009017R0102 is a high-performance excitation control module developed by ABB, specifically designed for synchronous generator excitation systems in power generation, industrial power supply and renewable energy applications. As a core component of the excitation control system, it is responsible for regulating the generator’s field current to maintain stable terminal voltage, optimize reactive power output and ensure the safe and efficient operation of the generator unit. The module integrates advanced digital control algorithms, real-time data acquisition and fault diagnosis functions, supports seamless communication with plant-level DCS and SCADA systems, and features redundant configuration capability to meet the high-reliability requirements of critical power generation equipment. Its robust design enables stable operation under harsh industrial conditions with electromagnetic interference, temperature fluctuations and vibration. |
| Product Parameters | 1. Control Core: 32-bit high-performance microprocessor with real-time operating system
2. Input Signals: 4-20 mA analog inputs (generator terminal voltage, field current, reactive power), discrete digital inputs (status signals) 3. Output Signals: 4-20 mA analog output (field current control signal), relay contact outputs (fault alarm, trip signals) 4. Power Supply: 24 V DC (nominal, 18-32 V DC range), power consumption ≤ 20 W 5. Communication Interfaces: RS485 (Modbus RTU), Ethernet (Modbus TCP/IP, IEC 61850 optional) 6. Control Accuracy: Terminal voltage regulation accuracy ±0.5% of rated value 7. Operating Temperature: -20°C ~ +60°C 8. Storage Temperature: -40°C ~ +85°C 9. Humidity Resistance: 5% ~ 95% RH, non-condensing 10. Response Time: ≤ 100 ms (voltage regulation response under load change) |
| Specifications | 1. Housing Material: Reinforced industrial-grade plastic with metal shielding for EMI protection
2. Mounting Type: Rack-mounted, compatible with ABB excitation system standard cabinets 3. Dimensions: Standard ABB module form factor (approx. 220 mm × 150 mm × 80 mm, subject to actual product) 4. Protection Grade |
