TRICONEX 2101
Product Description:
The TRICONEX 2101 is a versatile processor and I/O module used in industrial control and safety instrumented systems. It features Triple Modular Redundancy (TMR) architecture, providing fault-tolerant capabilities by simultaneously processing signals across three isolated channels. The module is designed for critical safety applications in process industries such as oil & gas, power, and chemicals, ensuring reliable operation and high availability. It delivers secure system control and is modular, supporting flexible installations with other Triconex components.
Product Parameters and Specifications:
-
Processor Configuration: Dual 32-bit RISC processors (MP2101S2 variant)
-
Memory: 32MB DRAM with ECC; 1MB (Baseplate model)
-
Channels Supported: 16-Channel I/O (for MP2101 variant)
-
Input/Output Voltage: Operates at 18–32 VDC
-
Maximum Current Consumption: 400 mA
-
Communication: 1x 10/100M Ethernet, 2x RS-485
-
Isolation: Triple Modular Redundancy (TMR) architecture for increased safety and reliability
-
Response Time: Typical cycle ~5 ms
-
Diagnostics: Onboard health monitoring with real-time fault warning accuracy of 98.5%, periodic memory cross-checking, extensive reporting
-
Safety Certification: IEC 61508 SIL2/SIL3, TÜV-certified for safety applications
-
Operating Temperature Range: –40°C to +70°C
-
Application: Emergency Shutdown Systems (ESD), Burner Management, Fire & Gas detection, process control
