The TK516 module is not a typical “module” in the sense of a circuit board or a discrete electronic component, but rather an accessory or a cable component used within ABB’s industrial control systems, specifically related to their Advant Fieldbus 100 communication. It’s often referred to as a “drop cable” or “modem” type connection for linking communication interfaces.
Additionally, in a completely different context, “SKF TK 516” refers to a taconite seal for bearing housings. It’s crucial to distinguish between these two very different products. Given the context of your previous questions (industrial automation modules), I will focus on the ABB communication component.
Product Name
ABB TK516 Advant Fieldbus 100 Drop Cable / Modem Cable (Sometimes referred to simply as “TK516 cable” or “TK516 modem”)
Product Description
The ABB TK516 is a specialized drop cable used in the Advant Fieldbus 100 system, which is a proprietary industrial communication network developed by ABB for its Distributed Control Systems (DCS), such as the Advant Controller 110 or Advant Controller 450.
This cable acts as an interface or connection component that allows a communication interface module (e.g., CI626 or CI630) within an ABB controller to connect to the main coaxial bus of the Advant Fieldbus 100 network. It facilitates the high-speed and reliable data exchange essential for real-time process control and monitoring within industrial automation environments. The cable typically terminates with a BNC connector for connection to the bus.
It is part of the physical layer of the communication network, ensuring proper signal transmission and impedance matching for the bus.
Product Parameters and Specifications
- Manufacturer: ABB
- Model Number: TK516
- Product Type: Drop Cable / Modem Cable for industrial fieldbus communication.
- System Compatibility: Primarily used with ABB Advant Fieldbus 100 systems, connecting to communication interfaces like CI626/CI630.
- Function: Connects the communication interface module of an Advant Controller (e.g., AC110, AC450) to the Advant Fieldbus 100 coaxial bus.
- Connectors: Typically features a BNC connector for the bus side. The other end connects to the communication interface module.
- Cable Type: Coaxial cable, designed for industrial fieldbus applications.
- Purpose: Facilitates data transmission over the Advant Fieldbus 100 network.
