TIS600-124
Product Description
The TIS600 – 124, crafted by Traco Power, is a high – performance power supply module tailored for industrial applications. It is a mature product that remains in production to support sustaining programs.
This module is specifically designed for industrial process control systems and machine tools. It offers outstanding specifications and remarkable immunity against electrical disturbances, which is crucial for providing reliable power to sensitive loads in rugged industrial environments.
The TIS600 – 124 features a single output with a fixed output voltage of 24 VDC. However, the output can be adjusted within the range of 24 – 28 VDC to meet specific application requirements. With a rated output current of 24000 mA (24 A), it has a power rating of 576 W, making it suitable for power – hungry industrial components.
It has a wide input voltage range, accepting both 93 – 132 VAC and 187 – 264 VAC. This versatility allows it to be used in various regions and power supply conditions. The module comes in a metal case, which not only provides physical protection but also aids in heat dissipation. It is designed for DIN – rail mounting, a standard and convenient method in industrial control cabinets, enabling easy installation and replacement. Screw – type terminals are used for connection, ensuring secure and reliable electrical connections.
Optional function modules can be added to the TIS600 – 124. For instance, with the UDS module, the power supply can be transformed into a DC – UPS with automatic battery – backup. This function is extremely useful in applications where a time – delayed shutdown of the system is necessary, such as in critical industrial processes where sudden power loss could lead to significant losses or safety hazards. Additionally, a signal module can be installed to monitor and control the power supply, providing real – time status information. There is also a redundancy option available for parallel operation with active power sharing, enhancing the reliability of the power supply system.
Product Parameters
- Manufacturer: Traco Power
- Model: TIS600 – 124
- Module Type: Power Supply Module
- Input Voltage: 93 – 132 VAC and 187 – 264 VAC
- Output Voltage: 24 VDC (Adjustable from 24 – 28 VDC)
- Output Current: 24000 mA (24 A)
- Power Rating: 576 W
- Number of Outputs: Single
- Efficiency: 90%
- Operating Temperature Range: – 25 °C to 70 °C
- Safety Approvals: EN 60950 – 1, EN 62368 – 1, UL 508
- Insulation System: Reinforced Insulation
- I/O Isolation Voltage: 3000 VDC
- Remote On/Off: No
- Weight: 2000 g
Product Specifications
- Physical Dimensions:
- Length: 243 mm
- Width: 83 mm
- Depth: 177.2 mm
- Mounting: DIN – rail mount
- Connection Type: Screw terminal
- Housing Type: Metal case
- Protection Level: Not specified in the given data, but cons
idering its industrial use, it may have some level of protection against dust and accidental contact, perhaps similar to IP20.
- LED Indicators: Not mentioned in the provided information. However, it is common for such industrial power supply modules to have LED indicators for power status, output voltage status, and potentially fault indicators. These would help operators quickly assess the module’s operating condition.
- Terminal Rating: The screw – type terminals are designed to handle the electrical currents and voltages associated with the module’s operation. They are likely rated to handle the 24 A output current and the input voltage ranges without overheating or causing electrical failures.
- Power Supply Ripple and Noise: Although not provided, for a high – quality industrial power supply module like the TIS600 – 124, the output power is expected to have low ripple and noise levels. This is important to ensure stable operation of sensitive electronic components connected to the power supply.
