SST-PFB-CLX
Product Description
The SST – PFB – CLX is a high – performance module engineered for industrial automation scenarios. It is designed to establish a seamless connection between Allen – Bradley ControlLogix processors and PROFIBUS DP remote I/O devices. By leveraging the PROFIBUS DP protocol, it enables efficient data exchange, real – time monitoring, and control of remote I/O units. This module serves as a crucial bridge, facilitating communication between the ControlLogix system and a wide array of external devices such as sensors, actuators, and other PLCs.
It features a user – friendly design, allowing for easy configuration and integration into existing industrial networks. With its industrial – grade build, the SST – PFB – CLX can withstand harsh environmental conditions, including temperature variations, vibrations, and electromagnetic interference, ensuring reliable operation in demanding industrial settings. Additionally, it supports various communication protocols like Modbus, Ethernet/IP, and of course, PROFIBUS DP, providing flexibility in connecting with different types of devices and systems.
Product Parameters
- Communication Protocol
- PRIMARY: PROFIBUS DP (supports both v0 slave and v1 master protocols). It enables high – speed data transfer with a communication speed of up to 12 Mbps, ensuring real – time response in industrial control applications.
- SUPPORTED: Modbus TCP/IP, Ethernet/IP, which allows for seamless integration with other industrial control systems and devices that adhere to these protocols.
- Interface
- CONFIGURATION: 1 x RS – 232 serial port. This port is mainly used for initial configuration of the module, allowing technicians to set parameters such as node address, communication baud rate, and protocol – specific settings.
- DATA TRANSFER: 1 x RS – 485 interface port (for PROFIBUS DP communication). It provides a reliable physical connection for data exchange between the module and PROFIBUS DP devices on the network.
- Power Supply
- OPTIONS: 5 VDC @ 850 mA or 24 VDC @ 1.75 mA. This dual – voltage option offers flexibility in powering the module, making it adaptable to different power supply setups in industrial environments.
- Operating Temperature
- RANGE: – 20 °C to + 60 °C (Some sources also mention – 25 °C to 70 °C). The module is designed to operate within this temperature range without performance degradation, ensuring continuous operation in both indoor and outdoor industrial applications where temperature variations are common.
- Certifications
- It holds certifications such as CE (compliant with EMC directive and LVD – Low Voltage Directive), UL / CUL, KC, ABB S approval, DNV approval, LR approval, GL approval, BV approval, RINA approval, NK. These certifications ensure that the module meets international safety, electromagnetic compatibility, and quality standards.
Product Specifications
- Module Type
- PROFIBUS DP remote I/O scanner module, specifically designed for integration with Allen – Bradley ControlLogix systems.
- Weight
- Approximately 0.54 kg (or 1 kg as per some sources). The relatively lightweight design makes it easy to install and reduces the overall load on the control system’s mounting structure.
- Dimensions
- Some sources suggest dimensions of around 3.5 x 14 x 14.5 cm (compact design), which allows for easy installation in control panels with limited space.
- Memory Capacity
- 512 KB RAM and 1 MB flash memory (as per some specifications). This memory capacity enables the module to store configuration data, buffer incoming and outgoing data, and support complex monitoring and control applications without significant performance bottlenecks.
- Input/Output Channels
- Some models may support 16 inputs / 16 outputs (configurable), which can be used to interface with a variety of field devices for data acquisition and control signal output.
