SCHNEIDER BMXDDM16025
The Schneider BMXDDM16025 is a discrete volume hybrid input/output module designed for the Modicon M340 PLC family. It has eight discrete input channels, can accept 24VDC signals from the sensor, and has leaky (positive logic) input characteristics. At the same time, it has 16 discrete output channels, which can provide solid state 24VDC output and relay output (24VDC to 240VAC), suitable for driving a variety of actuators or external devices. In addition, the mo
dule is equipped with a 20-pin FTB type connector for easy connection to external devices 1234.
Product parameters:
Model: BMXDDM160251234.
Type: Discrete quantity mixing module, DC input, DC/AC relay output 13.
Count: 8I/16O (8 inputs, 16 outputs) 13.
Input voltage: 24VDC13.
Output switching capacity: solid state output 24VDC/0.1A, relay output 24VDC to 240VAC, 3A23.
Connection method: BMXFTB2000/2010/2020 or flyline BMXFTW301/501/1001.
Enclosure protection class: IP2023.
