SCHNEIDER 140CPS12420
Description: The Schneider 140CPS12420 module is a redundant power supply module for the Modicon Quantum automation platform. It provides 24V DC power to the controller and I/O modules. The module has the following features:
High reliability
Hot swap
High efficiency
Low power consumption
Product parameters:
Input voltage: 115 V/230 V AC, 47… 63 Hz
Input current: 1100 mA @ 115 V, 600 mA @ 230 V
Maximum surge current: 19 A@ 230 V, 38 A@ 115 V
Rated power: [VA] 130 VA
Fuse for use with relay: 2 A, slow break type
Harmonic distortion: <= 10% basic RMS value
Output voltage: 5.1V DC
Power output current: 11 A@ 60 °C independent, 10 A@ 60 °C redundant
Output overvoltage protection: internal
Output overload protection: internal
Power consumption: 6 + (1.5x output current) Where the output current unit is A
Warning output: 1 NC 6 A 220 V power supply is faulty
Local signal indication: 1 LED (green) for power (PWR OK):
Mark: CE
Module classification: Standard
