ZYGO 8070-0279-01

Product Description: ZYGO 8070-0279-01 module is a 2-channel 24-bit analog input module produced by ZYGO Company. It has the following characteristics:

Provides 2 independent 24-bit analog input channels.

With over voltage, under voltage, over current, short circuit and other protection functions.
Supports multiple wiring modes, including 4-wire, 2-wire, transformer, and isolation.
Product parameters:

Input signal type: voltage, current, frequency, pulse width
Input range: -10V ~ +10V, 0 ~ 20mA, 0 ~ 10 kHz, 0 ~ 100 kHz
Resolution: 24 bits

Accuracy: ±0.01%
Sampling rate: 100 kHz
Protection function: over voltage, under voltage, over current, short circuit
Wiring mode: 4-wire, 2-wire, transformer, isolation
Dimensions: 90 x 28 x 18 mm
Specifications:

Product model: ZYGO 8070-0279-01
Product Description: 2-channel 24-bit analog input module
Input signal type: voltage, current, frequency, pulse width
Input range: -10V ~ +10V, 0 ~ 20mA, 0 ~ 10 kHz, 0 ~ 100 kHz
Resolution: 24 bits
Accuracy: ±0.01%
