Yokogawa AAI543-H61 /K4A00
The Yokogawa AAI543-H61 /K4A00 module is an analog output module produced by Yokogawa Electric for the Centum VP series control system with the following features:
4 channels analog output
Supports multiple output ranges
Easy to install and use
Product parameter
Parameter value
Module Type Analog output module
Number of channels 4
Output range ±10V, ±5V, ±1V, 0-10V, 0-5V, 0-1V
Resolution 16 bit
Update rate 1ms
Power supply 24V DC
Mounting method DIN rail mounting
Dimensions 96 x 96 x 48 mm
Weight 200g
specification
Ambient temperature: 0°C – 60°C
Relative humidity: ≤95% (non-condensing)
Vibration: ≤10g (5Hz-150Hz)
Impact: ≤50g (11ms)
