WOODWARD 8273-126

WOODWARD 8273-126 module
Product name

WOODWARD 8273-126 module

Product description
The WOODWARD 8273-126 module is the I/O module of the WOODWARD Governor Company 8273 series controllers. It can provide the controller with additional I/O interfaces for connecting various input and output devices. The module is characterized by high performance, high reliability and easy installation.

Product parameter
Number of channels: 16
Input type:

8 numeric inputs
8 analog inputs
Output type:
8 digital outputs
8 analog outputs
Input range:
Digit input: 0V to 24V
Analog input: 0V ~ 10V, 0V ~ 5V
Output range:
Digital output: 0V ~ 24V
Analog output: 0V ~ 10V, 0V ~ 5V
Resolution:
Digit input: 1 digit
Analog input: 12 bits
Analog output: 12 bits
Operating temperature: -40℃ ~ 85℃
Storage temperature: -55℃ ~ 100℃
Relative humidity: 5% ~ 95%
Overall dimensions: 110mm x 70mm x 40mm
