WESTINGHOUSE 5X00226G02

Product Description:

The WESTINGHOUSE 5X00226G02 module is an 8-channel analog input module for the Westinghouse DeltaV control system. The module is used to connect various analog sensors such as temperature sensors, pressure sensors, flow sensors, etc.

Product parameters:

davdavNumber of analog input channels: 8
Input signal type: 0 to 10 V, 4 to 20 mA
Resolution: 16 bits
Accuracy: 0.001V, 0.1mA
Power supply voltage: 24 V DC
Operating temperature: -20 to 60 degrees Celsius
Protection level: IP67
Specifications:

Dimensions: 120 x 70 x 25 mm

Weight: 100 g
Application field:

WESTINGHOUSE 5X00226G02 modules are widely used in various industrial sites, such as factories, buildings, municipalities, etc. It can be used to monitor the status of various industrial equipment, such as mechanical temperature, pressure, flow, etc.

Note:

The WESTINGHOUSE 5X00226G02 module is an industrial grade product, and the following should be noted when using it:

When using, attention should be paid to the limitation of voltage and current to prevent overvoltage or overcurrent from damaging the module.
When using, pay attention to the protection level to prevent water or dust into the module.
Pay attention to maintenance during use to prevent module damage.
