WESTINGHOUSE 1C31197G01

Number of analog input channels: 4
Input signal types: 0 to 10 V, -10 to 10 V, 4 to 20 mA, -20 to 20 mA
Input signal range: 0 to 10 V: 0 to 10 V, -10 to 10 V: -10 to 10 V, 4 to 20 mA: 0 to 20 mA, -20 to 20 mA: -20 to 20 mA
Resolution: 16 bits
Accuracy: 0.001V

Power supply voltage: 24 V DC
Operating temperature: -25 to 70 degrees Celsius
Protection level: IP67

Specifications:

Dimensions: 120 x 70 x 25 mm
Weight: 100 g
Application field:

Westinghouse 1C31197G01 modules are widely used in various industrial automation systems, such as process control systems, robot control systems, SCADA systems, etc. It can be used to measure various physical quantities, such as temperature, pressure, flow rate, speed, etc.

Note:

The Westinghouse 1C31197G01 module is an industrial grade product, and the following should be noted when using it:

When using, attention should be paid to the limitation of voltage and current to prevent overvoltage or overcurrent from damaging the module.
When using, pay attention to the protection level to prevent water or dust into the module.
Pay attention to maintenance during use to prevent module damage.
