Warner Electric M316-17-001
Product Description:
The Warner Electric M316-17-001 is a clutch/brake module for controlling motors. It uses a coil to control the engagement of the clutch or brake.
Product parameters:
Working voltage: 24V DC
Working current: 1.5A
Coil voltage: 24V DC
Coil current: 300mA
Clutch/brake type: winding spring
Clutch/brake diameter: 20 mm
Clutch/brake pull: 10 kg
Specifications:
Isolation: photoelectric isolation
Overvoltage protection: internal
Overload protection: internal
Short circuit protection: internal
Applications:
The M316-17-001 module can be used in the following applications:
Control motor start and stop
Control motor direction
