SCHNEIDER 140CPU65150
Product Description
The 140CPU65150 is a high – performance processor module in Schneider Electric’s Modicon Quantum series1. It combines the standard functions of a PLC with the diagnostic capabilities of a web server, offering advanced control and monitoring features1. It uses an RJ – 45 connection for communication, enabling easy integration into networked industrial systems1. Housed in a double – width standard Quantum enclosure, it requires two sequential slots in a Quantum rack1. With its powerful processing capabilities and rich communication interfaces, it is suitable for a variety of complex industrial automation applications.
Product Parameters
- Clock Frequency: 166 MHz1.
- Memory: 768 kB RAM, expandable 7168 kB program memory with PCMCIA card, expandable 8 MB file storage with PCMCIA card1.
- Data Rate: 10/100 Mbps1.
- Communication Protocols: Integrated connection types include Ethernet TCP/IP, Modbus, Modbus Plus, and USB. Supports standard web service, Modbus TCP messaging, etc1.
- I/O Configuration: 2 local racks, 63 distributed I/O stations, 1 rack, and 3 distributed networks. In the distributed network, there are 8000 discrete inputs and outputs, and in the remote system, there are 31744 discrete inputs and outputs. It can be used for time – stamping, as a counter, for high – speed interrupt inputs, and as a serial link1.
Product Specifications
- Dimensions: Not specified in the provided information, but it is in a double – width standard Quantum housing.
- Weight: Approximately 0.907 kg (2.00 pounds)1.
- Power Supply: 220 V (but it’s better to refer to the official manual for the exact range)6.
- Operating Temperature Range: Usually suitable for industrial environments, but the specific range is best obtained from the official datasheet.
