The Schneider TSXPBY100 module is an extension module in the Schneider Modicon M340 PLC family. It is a 100-channel digital input module used to convert digital signals into signals that can be processed by the PLC system. The module has the following features:
High density: 100 channel input
High speed: The input sampling rate can reach 100 kHz
Strong anti-interference ability: can resist electromagnetic interference and surge
Easy to install: DIN rail mounting
Product parameter
Input channels: 100
Input type: numeric input
Input voltage: 24 V DC
Input current: Maximum 20 mA
Input sampling rate: up to 100 kHz
Anti-interference ability: can resist electromagnetic interference and surge
Mounting method: DIN rail mounting
specification
Dimensions: 22.5mm x 100 mm x 125 mm
Weight: 0.5kg
Operating temperature: 0°C to 60°C
Storage temperature: -40°C to 85°C
Humidity: 5% to 95% (non-condensing)
