SCHNEIDER 140CRP93200

Product name: SCHNEIDER 140CRP93200

Product Description:

The SCHNEIDER 140CRP93200 is a 2-port RIO header adapter module for the Modicon Quantum series PLC. The module features a robust design for reliable operation in harsh environments. It has a variety of features, including:

Supports two RIO ports
Supports redundant cables
Supports a transmission rate of 1544 Mbit/s
Supports Modicon Quantum series PLC
Product parameters:

Ports: Two
Cable type: 75Ω coaxial cable
Transmission rate: 1544 Mbit/s
Dynamic range: 35 dB
Isolation voltage: 500 V DC coaxial center and ground
Electrical connection: 2-hole terminal F, curved with redundant cable
Diagnostic startup: power-on and runtime
RAM address/data performs checksum
Power consumption W: 3.8W Two channels
Required bus current: 750 mA for two channels
Module classification: Standard
Specifications:

Dimensions: 100 x 72 x 25 mm
Weight: 0.2 kg
Applications:

The SCHNEIDER 140CRP93200 module can be used in the following industrial applications:

Robot control
Process control
Data acquisition and monitoring
