RPSTECH DMP10.24

Product name: RPSTECH DMP10.24 module

Product Description: RPSTECH DMP10.24 module is an analog input module produced by RPSTECH for industrial control systems. It has an analog input channel that can measure analog signals from 0 to 10 V.

Product parameters:

Number of channels: one
Measurement range for each channel: 0 to 10 V
Power Supply: 24 V DC
Dimensions: 72 x 96 mm
Specifications:

Operating temperature: -40 ℃ to 70 ℃
Storage temperature: -40 ℃ to 85 ℃
Relative humidity: 5% to 95% (no condensation)
Vibration: 20 G rms, 10-50 Hz
Impact: 50 G, 11 ms
Applications:

The RPSTECH DMP10.24 module can be used in a variety of industrial applications, including:

Process control: Used to measure temperature, pressure, flow and other process variables.
Mechanical control: Used to measure position, speed, acceleration and other mechanical variables.
Data acquisition: Used to collect and store various analog signals.
Specific functions:

An analog input channel: can be used to measure various analog signals.
High accuracy: The module has an accuracy of up to 0.05%.
The RPSTECH DMP10.24 module is a powerful module that can be used in a variety of industrial applications.

Specific function description:

Analog input channel: An analog input channel can measure analog signals from 0 to 10 V.
A picture of the simulated input channel opens in a new window
www.taobao.com
Analog input channel

Measurement range: 0 to 10 V for each channel.

Accuracy: The module has an accuracy of up to 0.05%.

RPSTECH DMP10.24 module adopts Pt100, Ni100/120, Cu10 and other sensors, which can measure various process variables such as temperature, pressure and flow rate.

Note:

The RPSTECH DMP10.24 module has an input signal of 0 to 10 V, so a compatible device is required.
