REXROTH VDP40.2DEN-G4-NN-NN 15

Module: REXROTH VDP40.2DEN-G4-NN-NN 15
Product name
Bosch Rexroth VDP40.2DEN-G4-NN-NN 15 Touch screen

Product description

The REXROTH VDP40.2DEN-G4-NN-NN 15 is a color touch screen designed to control and monitor various industrial applications. It has the following characteristics:

15-inch TFT display with a resolution of 1024 x 768 pixels

High brightness LED backlight
Support multi-touch
Rugged housing for harsh environments
Rich communication interfaces, including RS-232, RS-422/485, USB and Ethernet
Product parameter
Parameter value
The display size is 15 inches
Resolution 1024 x 768 pixels
Backlit high brightness LED
Touch mode Multi-touch
Shell material Aluminum alloy
Protection class IP65
Communication interface RS-232, RS-422/485, USB, Ethernet
Power supply voltage 24 VDC
Power consumption < 25 W
Operating temperature -20°C to +60°C
Storage temperature -40°C to +85°C
specification
Specification value
Display type TFT
Display area 347.25 x 260.8mm
Viewing Angle 85°/85°/85°/85°
Brightness 400 cd/m²
Contrast ratio is 800:1
Response time 5 ms
Touch points 5
port
* 1 RS-232 interface
* 1 RS-422/485 interface
* 1 USB port
* 1 Ethernet interface |
