RELIANCE ELECTRIC WR-D4004

The Reliance Electric WR-D4004 module is a 4-channel, 12-bit analog output module for Reliance Electric’s AutoMax series frequency converters. The module can be used to output various analog signals, such as voltage, current, etc.

Product parameter

Number of channels: 4
Resolution: 12 bits
Accuracy: ±0.1%
Output range:

Voltage: 0 to 10 V, ±10 V
Current: 0 to 20 mA, ±20 mA
Update rate: 100 ms
specification
Size: 8HP
Power Supply: 24 Vdc
Power consumption: 2 W
Ambient temperature: 0 to 60 °C
Humidity: 5% to 95% (non-condensing)
Apply
Industrial control
Process control
Machine control
