PS6000
Product Name
PS6000Pro-face Modular Industrial Computing & Display System
Model Interpretation:
- “PS”: Denotes “Professional System,” aligning with Pro-face’s industrial-grade product positioning for reliable automation applications.
- “6000”: Series identifier signifying the platform’s mid-to-high performance tier, distinguishing it from entry-level (PS3000) and advanced (PS9000) lines.
- Variants (e.g., PS6000 Basic Box, PS6000 Panel) specify form factors (box-style for embedded use vs. panel-style with integrated display) .
2. Product Description
The PS6000 is a modular industrial computing system engineered by Pro-face for high-reliability automation control, human-machine interaction (HMI), and data visualization across manufacturing, logistics, and process industries. As a flexible core for industrial IoT (IIoT) integration, its core functions include:
- Executing real-time control logic and running HMI software (e.g., GP-Pro EX) via a powerful Intel Atom quad-core processor, supporting Windows 10 IoT Enterprise for compatibility with legacy and modern applications .
- Enabling seamless connectivity with PLCs, sensors, and cloud platforms through expandable I/O interfaces (e.g., RS-232/485, Ethernet, USB), with support for industrial protocols like Modbus and PROFINET.
- Delivering clear visual feedback via optional integrated displays (12”–19” wide-screen) with high brightness and anti-glare coating, optimized for harsh factory floor visibility .
- Ensuring operational continuity with rugged design features (fanless cooling, wide voltage input) and built-in diagnostics for power, temperature, and communication faults .
Key technical strengths:
- Modular Flexibility: Available as a “Basic Box” (for embedded integration) or “Panel” (with display), supporting custom configurations via expansion modules (e.g., additional I/O, wireless adapters) .
- Rugged Performance: Fanless operation (-10°C to 50°C operating range) and resistance to electrical interference (1,500Vp-p surge protection) make it suitable for dusty, vibration-prone environments .
- IIoT-Ready: Dual-channel DDR4 memory (up to 32GB) and Intel UHD graphics enable data-intensive tasks like real-time analytics and video monitoring .
- Global Compliance: Certified to UL Class 1 Division 2 and EN 62368-1 standards, ensuring safe deployment in hazardous and commercial settings .
3. Product Parameters
| Parameter Category | Specific Specifications |
|---|---|
| Computing Performance | CPU: Intel Atom X6425E (quad-core, 1.8GHz) ;
Memory: 2× DDR4 SO-DIMM slots (up to 32GB total, 3200MHz, ECC-supported) ; Graphics: Intel UHD Graphics (shared memory, up to 50% of RAM) ; Storage: 2.5” SATA SSD/HDD bay (up to 2TB) |
| Electrical Ratings | AC Model:
– Input Voltage: 100–240V AC (85–264V range) ; – Power Consumption: 67VA (idle), 140VA (max) ; – Surge Current: ≤30A ; DC Model: – Input Voltage: 24V DC (18–31.2V range) ; – Power Consumption: 56W (idle), 121W (max) ; – Allowable Power Interruption: ≤5ms |
| Environmental Limits | Operating Temperature: -10°C ~ 50°C (fanless) ;
Storage Temperature: -40°C ~ 70°C ; Relative Humidity: 10%–90% RH (non-condensing) ; EMC Protection: 1,500Vp-p (AC model), 1,000Vp-p (DC model) |
| Safety & Compliance | Certifications: UL Class 1 Division 2, CE, EN 62368-1 ;
Insulation Resistance: ≥10MΩ (500V DC, power to PE) ; Dielectric Strength: 1,500V AC (1min, power to PE) |
4. Product Specifications
4.1 Physical & Mechanical
- Basic Box (Embedded):
- Dimensions (W×H×D): 180mm × 110mm × 50mm ;
- Weight: ~1.2kg ;
- Housing: Aluminum alloy (IP40-rated) ;
- Panel (With Display):
- Display Sizes: 12”, 15”, 19” wide-screen (1920×1080 resolution) ;
- Dimensions (15”): 350mm × 260mm × 55mm ;
- Weight (15”): ~3.5kg ;
- Housing: Polycarbonate (IP65 front panel) 。
4.2 Interface & Connectivity
- Standard Interfaces: 2× Gigabit Ethernet (RJ45), 4× USB 3.0, 2× RS-232/485, 1× HDMI 2.0 ;
- Expansion Options: PCIe Mini Card slot (Wi-Fi 6, 4G LTE), GPIO module (8× digital I/O) ;
- Audio: 3.5mm headphone/microphone jack, built-in speaker (panel models) 。
4.3 Software & Compatibility
- Operating System: Windows 10 IoT Enterprise 2021 LTSC (64-bit) ;
- Supported Software: GP-Pro EX (HMI development), Blue Open Studio (IIoT integration), WinCC (Siemens compatibility) ;
- Protocols: Modbus RTU/TCP, PROFINET, Ethernet/IP, MQTT 。
4.4 Installation & Maintenance
- Mounting: 19” rack (2RU), wall-mount, or VESA mount (panel models) ;
- Cooling: Passive (fanless) with aluminum heatsink ;
- Maintenance: Tool-less access to memory/storage; remote diagnostics via Pro-face Support Suite ;
- Warranty: 3 years (standard), 5 years (extended) 。
This system’s modular design, rugged performance, and IIoT capabilities make it a versatile solution for industrial computing and HMI applications. Its compatibility with Pro-face’s software ecosystem simplifies integration with existing automation infrastructure, while global certifications ensure compliance across regions.
