ProSoft MVI56-PDPMV1

ProSoft MVI56-PDPMV1 module is a PROFIBUS DP master station communication module produced by ProSoft Technology Company for ControlLogix processor to connect to PROFIBUS DP network, belonging to the MVI56 family. The module has the following features:

Supports PROFIBUS DP V0 and V1 protocols
Supports 12Mbit/s communication rate

Supports a maximum of 240 slave devices
Supports multiple diagnostic functions
Product parameters:

Model: MVI56-PDPMV1

Type: PROFIBUS DP Master station communication module
Supported protocols: PROFIBUS DP V0, PROFIBUS DP V1
Communication rate: 12Mbit/s
Maximum number of slave stations: 240
Indicator: Module status indicator, communication status indicator
Power supply: 24VDC
Power consumption: 10W
Operating temperature: 0℃~60℃
Storage temperature: -40℃~85℃
Relative humidity: 5%~95% (no condensation)
Protection level: IP20
Installation method: guide rail installation
Size: 89mm x 64mm x 25mm
Weight: 0.25kg
Product Specifications:

Supports multiple configuration tools
