Application Scenarios

At a packaging equipment manufacturer in Germany, a new line of carton erectors required a cost-effective yet fully compliant safety solution for emergency stops and access door interlocks. Using traditional contactors would have failed Category 3 requirements, while a full safety PLC was overkill for this standalone machine. The engineering team selected the PILZ 301120—wiring two e-stop buttons and a hinge-mounted safety switch directly into its input circuit. During a CE certification audit, the system passed Category 4 verification on the first attempt, thanks to the PILZ 301120’s force-guided contacts and self-monitoring design. Maintenance technicians later praised its clear LED diagnostics: when a door switch failed due to mechanical wear, the “CH1” LED remained off, enabling a 5-minute pinpoint repair—demonstrating how the PILZ 301120 turns safety compliance into operational efficiency.

Parameter

表格

Technical Principles and Innovative Values

Innovation Point 1: Force-Guided Contact Technology – All safety contacts in the PILZ 301120 are mechanically linked so that if one contact welds shut, the others cannot close—ensuring fail-safe behavior even under fault conditions, a requirement for Cat. 4 and PL e.

Innovation Point 2: Integrated Self-Monitoring – On power-up and during each reset cycle, the PILZ 301120 performs an internal diagnostic check of its relay coils and contact positions, preventing undetected dangerous failures.

Innovation Point 3: Manual Reset for Controlled Restart – Unlike automatic-reset relays, the PILZ 301120 requires an intentional human action to restart after a safety event—preventing unexpected machine motion and aligning with ISO 13850.

Innovation Point 4: Universal Compatibility – Designed to interface directly with virtually any safety-rated device—emergency stop buttons (NC contacts), safety limit switches, light curtains (OSSD outputs via adapter), and two-hand controls—without additional logic modules.

Application Cases and Industry Value

In a U.S.-based automotive parts stamping facility, legacy machines lacked proper e-stop monitoring, posing OSHA compliance risks. Retrofitting each press with a PILZ 301120 allowed engineers to daisy-chain existing NC e-stop buttons into a monitored safety circuit within hours. Post-installation, the plant passed its OSHA inspection with zero citations, and maintenance logs showed a 60% reduction in “nuisance trips” due to clearer fault indication—operators could instantly distinguish between a real e-stop activation and a wiring fault.

Similarly, in a food processing plant in Australia, the PILZ 301120 was used to monitor hygiene doors on a pasteurizer. When a door seal degraded and caused intermittent contact bounce, the relay’s fast response prevented unsafe operation during high-temperature cycles. Plant managers noted that the unit’s IP20 rating and wide temperature tolerance (–25°C to +60°C) ensured reliability in washdown environments—proving the PILZ 301120 excels not just in factories, but in demanding hygienic applications too.

Related Product Combination Solutions

PILZ PNOZ X2.1P (301130): Dual-channel version for redundant inputs—ideal for light curtains or dual e-stop circuits.

PILZ PNOZsigma PNOZ s30 (772133): Modular safety relay base—allows expansion with additional output or input modules alongside PILZ 301120.

PILZ PSENmag M1S (572100): Magnetic safety switch—perfectly matched to PILZ 301120 for non-contact door monitoring.

PILZ PSENopt II (630300): Safety light curtain—can be connected to PILZ 301120 via OSSD-to-relay adapter for basic muting-free applications.

PILZ PNOZ X1 C (774100): 24 VDC version of the same relay—used in low-voltage control panels.

PILZ PNOZmulti 2: Configurable safety controller—recommended when more than 3 safety zones are needed, offering a scalable upgrade path from PILZ 301120.

PILZ PNOZ X1P Accessories (e.g., 787500 terminal cover): Enhances finger protection and labeling clarity for PILZ 301120 installations.

PILZ MyPNOZ: Cloud-enabled modular safety system—represents the next-generation evolution beyond fixed-function relays like PILZ 301120.

Installation, Maintenance, and Full-Cycle Support

Installing the PILZ 301120 is straightforward: mount it on a standard 35 mm DIN rail, connect input devices (e.g., e-stop NC contacts) to terminals S11/S12. wire safety outputs to contactors or drives, and link a momentary pushbutton to the reset terminals (R/R). No software or configuration is required—making it ideal for rapid deployment. Its compact 22.5 mm width conserves panel space, while clearly labeled terminals and color-coded LEDs simplify troubleshooting.

For maintenance, the PILZ 301120 features a mechanical life of >1 million operations and electrical life of >100.000 cycles at rated load. Routine checks include verifying LED behavior during reset and inspecting for terminal corrosion in humid environments. In the rare event of failure, replacement takes less than 5 minutes with no re-engineering. We provide comprehensive support including pre-shipment functional validation, application-specific wiring diagrams, and global technical assistance. Every unit is tested to PILZ’s stringent quality standards and backed by a 24-month warranty.

Contact us for a customized solution—whether you’re designing a new machine, retrofitting legacy equipment, or building a global spare parts inventory, the PILZ 301120 delivers trusted, certified safety in the simplest possible form.
