NI USB4065

The NI USB-4065 module is a high-performance data acquisition module from NI that can be connected to the USB port of a PC or laptop for measuring voltage, current, resistance, temperature and other signals. The module has the characteristics of 6.5 bit res

olution, 5kS/s sampling rate, and various measurement functions, which can meet the needs of various industrial control, laboratory testing, data acquisition and other applications.

Product parameter

Measuring range:

Dc voltage: ±300V
Ac voltage: ±300V
Dc current: ±1A
Ac current: ±1A
Resolution: 6.5 bits
Maximum sampling rate: 5kS/s
Resistance measurement range: 300Ω to 100MΩ
Capacitance measurement range: 1nF to 1000µF
Temperature measurement range: -200°C to 1800°C
specification

Dimensions: 98mm x 63mm x 25mm
Weight: 150g
Operating temperature: 0°C to 55°C
Storage temperature: -40°C to 71°C
Operating humidity: 10% to 90%, no condensation
