NI SCXI-1193

NI SCXI-1193 is a high density, high performance multiplex switching module for NI’s SCXI data acquisition system. The module can connect multiple analog signal sources to a single analog input channel, so as to realize the switching and multiplexing of multiple signals. The module has the following features:

High density: Supports switching and multiplexing of up to 32 analog signals.

High performance: Provides high switching speed and low leakage current to meet demanding measurement needs.
Multiple topologies: Supports multiple topologies, including single-ended, differential, grounded, and floating topologies, to meet different application requirements.
Flexible configuration: The software can be flexibly configured to meet various application requirements.
Strong compatibility: Compatible with NI SCXI data acquisition system.
Product parameters:

Parameter value
Number of channels 32
Switching speed < 1μs
Leakage current < 1 pA
Supports single-ended, differential, grounded, and floating topologies
Operating temperature -40°C to +85°C
Storage temperature -55°C to +125°C
Humidity 5% to 95% RH (non-condensing)
Protection class IP65
Dimensions 115 mm x 65 mm x 25 mm
Weight 0.2kg
