NI PXIE-4145

The NI PXIE-4145 module is a high-performance, high-precision, 4-channel precision Source Measurement Unit (SMU) module manufactured by National Instruments (NI). The module uses the PXI Express interface and can be easily assembled into a complete test system with other PXI modules.

Product parameter

Model: NI PXIE-4145
Number of channels: 4

Voltage range: ±10V, ±1V, ±100mV, ±10mV, ±1mV, ±100μV
Current range: ±1A, ±100mA, ±10mA, ±1mA, ±100μA, ±10μA
Measurement accuracy: 7.5 bits
Sampling rate: 20 MHz
Maximum output power: 40W
specification
Specification parameter
Model NI PXIE-4145
Number of channels 4
Voltage range ±10V, ±1V, ±100mV, ±10mV, ±1mV, ±100μV
Current range ±1A, ±100mA, ±10mA, ±1mA, ±100μA, ±10μA
The measuring accuracy is 7.5 bits
Sample rate 20 MHz
