NI PCI-6115

NI PCI-6115 Multi-function Data acquisition (DAQ) device

Product description

The NI PCI-6115 is a high-performance, versatile DAQ device for PCI buses. It has the following characteristics:

4 analog input channels (12-bit resolution, 10 MS/s sampling rate)
Two analog output channels

Eight digital I/O channels
2 24-bit counters
Supports multiple trigger modes
Easy to program
Product parameter
Parameter value
Number of analog input channels 4
Analog input resolution 12 bits
Analog input sampling rate 10 MS/s
Number of analog output channels 2
Number Number of I/O channels 8
The counter has 2 24-bits
Trigger mode Triggered by software, hardware, or external
Interface PCI
Supply voltage ±12 V, 5 V
Power consumption < 10 W
Operating temperature 0°C to 60°C
specification
Specification value
Dimensions 229 x 121 x 21 mm
Weight 0.5kg
