MOOG D136-001-007

The Moog D136-001-007 is a versatile and reliable eight-channel analog input/output module designed specifically for industrial automation applications. It provides eight analog input channels and eight analog output channels, which can be used to measure and control various analog signals. The module has the following features:

Hybrid I/O channels: Provides a combination of eight analog input channels and eight analog output channels.

High accuracy: Analog input channels provide high accuracy with resolution up to 16 bits.
Wide signal range: The analog input channel supports a wide signal range from -10 V to +10 V.

Flexible output modes: Analog output channels support multiple output modes, including voltage and current.
High isolation voltage: Provides high isolation voltage between analog input and output, up to 2500Vrms, effectively preventing fault and noise interference.
Rugged: Rugged design to withstand harsh industrial environments, operating temperature range -40°C to +85°C.
Product parameters:

Parameter value
Number of analog input channels 8
Analog input resolution 16 bits
Analog input range -10 V to +10 V
Number of analog output channels 8
Analog output resolution 16 bits
Analog output mode voltage, current
Isolation voltage 2500Vrms
Operating temperature -40°C to +85°C
Storage temperature -55°C to +105°C
Humidity 5% to 95% RH (non-condensing)
Protection class IP65
Dimensions 115 mm x 65 mm x 25 mm
Weight 0.2kg
