MOOG C633-0001-R02KO1M0VSE2

Product description
MOOG C633-0001-R02KO1M0VSE2 is a 1-channel 16-bit analog input module for MOOG 3200 series servo drives. The module can be used to collect various analog signals, such as voltage, current, temperature, etc.

Product parameter

Parameter value
Number of channels 1

Resolution 16 bit
Input voltage range ±10 V
Input current range ±20 mA
Sampling rate 1 kHz
Interface RS-232, GPIB
Power supply voltage 24 VDC
Power consumption < 10 W
Operating temperature 0°C to +40°C
Storage temperature -20°C to +60°C
specification
Specification value
Dimensions 100 x 50 x 20 mm
Weight 0.5kg
Apply
The MOOG C633-0001-R02KO1M0VSE2 module can be used in a wide range of industrial control applications, including:

machining
Robot
Packaging machinery
Printing machinery
