MOOG D136-001-007
Description: D136-001-007 is an electro-hydraulic servo valve driver module produced by MOOG Company. It can provide high-precision and fast-response control signals for electro-hydraulic servo valves, so as to drive the hydraulic system to achieve high-precision position, speed and force control. The module has the advantages of high reliability, good stability and long service life, and is widely used in aviation, aerospace, energy, chemical industry and other fields.
Product parameters:
Input voltage: +12V DC
Output current: 0 to 20mA
Response frequency: ≥100Hz
Linearity: ≤0.1%
Operating temperature: -55℃ to +125℃
Dimensions: Approx. 3.4 “x 2.4” x 1 “(86mm x 61mm x 25mm)
Weight: About 0.4 kg
Specifications:
Mounting method: rail mounting or surface mount
Connection mode: Cable connection
