Honeywell ASW454
Product Description:
The Honeywell ASW454 module is a 4-channel analog input module for ControlLogix controllers. It can provide 0-10V or 4-20mA analog signals.
Product parameters:
Working voltage: 24V DC
Working current: 30 mA/channel
Input type: Analog input
Input voltage: 0-10V or 4-20mA
Input current: 20 mA/channel
Input impedance: 100 kΩ / channel
Input isolation: photoelectric isolation
Input overvoltage protection: internal
Input overload protection: internal
Local signal indication: 4 leds (green) for power (PWR OK) and 0-10V or 4-20mA
Mark: CE
Module classification: Standard
Net weight: 0.13 kg
Specifications:
Dimensions: 127 x 90 x 40 mm
Weight: 120g
Applications:
The ASW454 module can be used in the following applications:
Temperature measurement
Pressure measurement
