HIMA F6217
Product name: HIMA F6217 module
Product Description:
The HIMA F6217 module is an 8-channel analog input module for collecting various industrial signals such as temperature, pressure, flow, etc. The module has high precision and high reliability, which can meet the needs of industrial automation applications.
Product parameters:
Number of inputs: 8
Input type: differential
Input voltage: 0… 5 V/0… 10 V
Input current: 0… 22 mA
Input impedance: 100 kΩ
Resolution: 12 bits
Absolute accuracy error: +/ -0.025% full scale
Linearity error: +/- 0.005% full scale
Temperature deviation accuracy: +/- 0.001% full scale /°C
COMMON MODE REJECTION: > 70 dB 60 Hz
Insulation between each channel and bus: 1000 V AC for 60 s
Update time: 20 ms
Fault type: Disconnected
Mark: CE
Local signal indication: 8 leds (green) for channel Open: 8 leds (red) for channel failure:
Required bus current: 120 mA
Power consumption W: 2 W
Module category: Security related
Specifications:
Dimensions: 96 mm x 96 mm x 9.5 mm
Weight: 0.1kg
Operating temperature: -25°C to +70°C
